Gluing Machine TG - 55
Top gluing machine TG 55 is Two roller top side gluing machine for cold glue. The indigenously designed roller and bottom plate design enables pasting on 70 gsm to 1000 gsm thick paper sheets in same settings. The new TG 55 can glue up to 10 mm thick boards. Glue and feed rollers are easily detachable for cleaning of the machine. TG 55 is virtually maintenance free. Hot glue option available in bottom gumming machine (HG 55).
Application : Back to back pasting jobs, Album making, Board Laminating
Gluing Machine Salient Features
- Heavy duty frame structure and wall
- Smooth AC drive with variable roller speed
- Indigenous roller & returner blade design to carry pasting on 0.07 to 1.0 mm thick materials
- Easily removable feed roller and glue roller system to provide full space for cleaning
- Glue tank above gluing rollers with knob for required continuous glue input.
- Adjustable glue thickness with precise self alignment roller
- 100 Micron thick hard chrome plated roller/ Stainless Steel rollers (Optional)
- Easily removable bottom tray for excess glue collection and reuse.
- Best quality control panel components used.
Gluing Machine Applications:
- Gluing machine for wedding card papers
- Glunig machine for tag manufacturing
- Gluing machine for back to back pasting
- Gluing machine for album making
- Gluing machine for board to board pasting
- Gluing machine for jewlery box making
- Gluing machine for velvet box making
- Gluing machine for box making
Hot Melt Top Gluing Machine: (Optional Attachment) Salient Features
- Top Gluing Machine TG-55 integrated with optional circulating hot melt attachment for high quality results for making high end and expensive products
- Precise digital glue temperature controller
- Dual tank heating system for indirect and uniform heating of glue
- Inbuilt system for cold glue applications
- Very easy cleaning system of rollers
- Integrated with high quality & durable piping system for hot glue
Hot Melt Top Gluing Machine Applications:
- Hot melt top gluing machine for wedding card papers
- Hot melt top glunig machine for tag manufacturing
- Hot melt top gluing machine for back to back pasting
- Hot melt top gluing machine for album making
- Hot melt top gluing machine for board to board pasting
- Hot melt top gluing machine for jewlery box making
- Hot melt top gluing machine for velvet box making
- Hot melt top gluing machine for box making
Gluing Machine TG - 55
TECHNICAL DATA (mm)
|
TOP GLUING TG 55
|
TOP GLUING TG 75
|
Max. paper size
|
500 mm (W) x 810 mm (L)
|
750 mm (W) x 810 mm (L)
|
Min. paper size
|
60 mm (W) x 150 mm (L)
|
60 mm (W) x 150 mm (L)
|
Paper thickness
|
70 gsm To 170 gsm
|
70 gsm To 170 gsm
|
Type of glue
|
Cold
|
Cold
|
Motor power
|
1 HP AC variable drive
|
1 HP AC variable drive
|
Max. Speed*
|
45 m/min
|
45 m/min
|
Materials
|
Paper, laminated paper, plastic coated paper, cloth etc.
|
Paper, laminated paper, plastic coated paper, cloth etc.
|
Floor space**
|
2000 mm (L) x 1000 mm (W) x 1200 mm (H)
|
2000 mm (L) x 1200 mm (W) x 1200 mm (H)
|
Hot glue option available in bottom gumming machine. Model: HG 55
|
||
